VSI Sand Maker

VSI Sand Maker

Processing Capacity: 60-520t/h

Max.Feeding Size: 30-50mm

Applied Material: limestone, basalt, river pebble, granite, quartz, iron ore, diabase, etc.

Email us: sell@hxjq.com

The Handling Materials and Application of VSI sand maker:

The VSI sand maker is a kind of first-class sand making equipment that Hongxing Machinery designed by combining advanced technology from Germany with the actual situation of China's sand making industry and then improving for many times. It mainly provides high-quality sand and gravel aggregates for high-rise building construction, highway construction, municipal engineering, large-scale water conservancy facilities, concrete mixing stations and other fields.

VSI Crusher

Features

I. High Crushing Ratio

The crushing chamber with anvils enhances the crushing efficiency.

II. High Throughput

Rotors with the deep cavity enables greater throughput.

III. Easy to Maintain

Thanks to the hydraulic opening device, it is easy to maintain and repair.

IV. Optimum Product Shapes

Its finished products are cubic with the reasonable gradation, and the fineness can be adjusted.

V. Thin Oil Lubrication

The thin oil lubrication solution that can be recycled provides a wider range of speeds.

VSI Crusher

Services

We have professional engineers who can customize the most economical engineering solutions based on the project information you provide. The VSI sand making machine has low investment but high profits, which is an option that investors should not miss. We can tailor solutions to maximize your business profitability. You can leave your contact information and product requirements in the message form below, such as material, capacity, etc. Or you can send an email to sell@hxjq.com. We will contact you as soon as possible.

Technical Parameter

Model HXVSI-7611 HXVSI-8518 HXVSI-9526 HXVSI-1140 HXVSI-1145 HXVSI-1150
Capacity
(t/h)
Feed both
at center
 and sides
120-180 200-260 300-380 450-520 500-610 520-650
Feed at
center
60-90 100-130 150-190 225-260 245-355 255-365
Max.feeding
size(mm)
Soft
material
35 40 45 50 50 50
Hard
material
30 35 40 40 45 45
Rotation
speed
(r/min)
1700-1890 1520-1690 1360-1510 1180-1310 1150-1300 1150-1300
Double Motor
power(kw)
4P   110 4P   180 4P   264 4P   400 4P   400 4P   500
Overall dimension
(L×W×H)(mm)
3700×2150×2100 4140×2280×2425 4560×2447×2778 5100×2700×3300 5500×2700×3300 5500×2700×3300
Power supply 380V 50HZ
Lubrication
station
Double
motor
power of
oil pump
2×0.31Kw
Safety
assuance
Double oil pumps assure enough oil supply:automatic
 switch off with no oil stream or pressure,water cooling
in summer,motor heating stare-up in winter.
Overall
dimension
(L×W×H)
(mm)
820×520×1270
Power of oil
 tank heater
2KW
